Dixell XR80CX 0P0C1 cooling thermostat with 12V power supply and mixing control

The Dixell XR80CX panel mount and XR80D DIN rail mount controller models are controllers designed for milk cooling and storage, air drying applications, or other applications that utilize the combined control of a cooling unit and additional equipment such as a fan, mixing equipment, etc. They are equipped with two relay outputs: to control the compressor of the refrigeration unit and the auxiliary equipment (fan/mixer).

These thermostats allow precise control of the entire milk storage cycle in the tanks. The auxiliary output for the agitator/fan can also be triggered by pressing a button on the controller panel, in addition to automatic start-up (which can be set via controller parameters). Parameters can be easily copied with the HOT KEY programming key and the latest temperature alarms are recorded using the new HACCP function.

Benefits and features of the Dixell XR80CX and XR80D series controllers:

• Innovative controller suitable for normal and low temperature heating and cooling applications
• Simple and intuitive programming
• Direct on/off button
• Activation of economical cooling mode via digital input
• Fast freezing thanks to dedicated setpoint
• Output restart on open door alarm
• Minimum and maximum temperature functions
• Option to set the digital input as a temperature sensor
• Management of virtual temperature probes
• Cycles for milk cooling and storage
• Functions for air drying in automated processes
• Condenser temperature management to prevent critical situations
• HotKey or ProgTool connector for quick and easy programming
• Serial communication allows connection to remote management systems
• Connection for remote X-Rep display (alternative to TTL output)
• Maximum power consumption 3VA
• Display with status icons and 10.5mm high digits
