Dixell XT420C 5C1P0 controller with timer
- Two-state ON/OFF controller with integrated timer
- dual display with simultaneous temperature and time display
- status icons for displaying controller status
- pTC or NTC sensors can be connected to the input
- two control outputs
- auxiliary voltage-free digital input
| Power supply | 230 Vac |
| Design (panel size) | 32 x 74 mm |
| Type of regulation | On/off |
| Control input | Temperature sensor |
| Output - relay | 2x |
| Display digit colour | Two colours |
| Producer | Dixell |
Dixell XT420C are two-state ON/OFF temperature controllers for direct or inverse operation (heating or cooling), typically used to control cookers, ovens, thermo baths, pasteurizers and other gastro equipment. A built-in timer allows limiting the controller's operating time, including cycle end signaling.
A PTC or NTC type sensor can be connected to the temperature input.
These Dixell XT420C controllers feature a digital input, buzzer and can be programmed quickly and easily with the HOT KEY programming key. The basic version also includes a TTL output for connecting the controller to serial communication.
The controllers are panel mounted with front dimensions of 32 x 74 mm.
| TECHNICAL PARAMETERS | |
|---|---|
| Power supply | 230 Vac ±10 %, 50/60 Hz |
| Power input | max 5VA |
| Accuracy at 25 °C | ± 0,5 °C |
| Sampling time : | 1s |
| Front Panel Coverage | IP65 with RG-C seal |
| Operating conditions | 0...60°C, 20...80% humidity |
| Input | PTC (NTC) thermistor(-50 to 140°C) |
| Other inputs | digital input - Voltage-free contact |
| Outputs | 2x switching relays 8(3) A / 250 V |
| Other outputs | TTL output for serial communication (output for HOT KEY programming key) buzzer |
