Mini PLC Pixsys PL110-1A without display

Pixsys PL110-1A is a powerful mini PLC, ideal for integrating sequential control functions, data processing and management on automatic machines or DOMOTIC smart home systems with analogue variable control and digital/analogue blocks. The single device offers digital inputs and relay outputs, analog inputs for NTC probes (-40 ... +125°C) and for linear voltage and current signals (1024 points) and linear analog output (256 points). For networking, it includes two multi-point RS485 serial ports up to 57000 Baud.

The PLprog programming environment is divided into easy-to-use blocks that, in addition to the classic counters, timers and control with PID algorithms, also implements functions such as axis positioning, various mathematical functions and 16-bit logic.

The development environment uses a normal USB cable connection to program the device. Wiring is simplified as much as possible with removable terminals, and for applications with a small number of I/Os, it remains a subtle device with little space requirements. Thanks to its modularity, the Pixsys PL110-1A can be expanded with Pixsys MCM260 expansion modules. The OLED display option allows the display of predefined pages with program variables and I/O status. This version does not include a display.
