Rugged Ebro EBI 12-T100 temperature data logger with internal sensor, -90 to +150°C

The ebro EBI 12 series of ruggedized loggers are designed for accurate measurement of basic physical quantities under extreme conditions such as those found in medical sterilizers, food sterilization and pasteurization lines, laboratories and other demanding applications. Data transmission is wireless, using an interface (not included, must be ordered separately).

The data logger itself has no controls, everything is handled by wireless transmission from the interface. Thanks to this solution, the data loggers offer unrivalled durability and long service life, even in the harsh conditions that prevail in medical and laboratory sterilizers, or for example in the rinsing lines of returnable beverage containers. Data can be wirelessly read from the recorder after the measurement is complete.

Power supply is provided by a lithium battery, programming is done from a computer via an interface. The Ebro EBI 12 range of recorders includes many different models to suit different requirements.

Depending on the model, the Ebro EBI 12 series recorders allow:

• Record temperature / pressure / humidity / conductivity in process monitoring
• Hot or cold process monitoring in the temperature range from -200 to +400°C
• Possibility to record up to 4 different channels/sensors simultaneously
• Up to 100,000 values recorded and stored
• Choice of temperature probe: internal, external flexible, external fixed
• Choice of external probe diameter: O 1.2, 1.5, 3.0 or 6.0 mm
• Optional length of external probe with radial or axial positioning on the recorder housing
• Available with blunt or needle end
• Connection to pressure sensor using standard M10 female thread for hose, flange or adapter
• Real-time wireless process monitoring, process validation
• Temperature measurement accuracy up to ±0.05°C
• Pressure measurement accuracy up to ±0.25 mbar
• Waterproof IP68 / NEMA 6P
• User can monitor instantaneous readings on the monitor
• Imperfect processes can be immediately detected and stopped if necessary
• Real-time process monitoring saves time and costs
• Models also suitable for explosive environments

Ebro EBI 12 recorders comply with the following standards:

• DIN EN ISO 17665
• DIN EN 285
• DIN EN ISO 15883
• DIN EN 13060
• DIN SPEC 58929
• DIN EN ISO 11135
• DIN EN ISO 25424
• DIN EN ISO 11140-4
• DIN EN ISO 9241
• DIN 12880
• DIN EN ISO 13408-3
• DIN EN ISO 14937
• ISO/IEC 25051
• FDA 21 CFR Part 11
• FDA 21 CFR Part 210-211
