Solid State Relay Maxwell MS-3DA4825 25A Three Phase

Three-phase solid state relay (SSR), switched and open at zero, suitable for applications with frequent switching of resistive loads.
Solid State Relay Maxwell MS-3DA4825 25A Three Phase
Solid State Relay Maxwell MS-3DA4825 25A Three Phase
Solid State Relay Maxwell MS-3DA4825 25A Three Phase (1)
Solid State Relay Maxwell MS-3DA4825 25A Three Phase (2)
32,33 EUR 26,72 EUR excl. VAT
On request
In person in Prague:on requestWith a delivery company:on request
CodeCH-010-570MAXPN3F SSR, ovládání 5-32 Vss, spínání 25 A, 480 VstřProducerMAXWELL electrical limitedWarranty2 years

Thermal conductive paste 10ml 0,9W/mK

Thermal conductive paste 10ml 0,9W/mK
In stock
9,00 EUR excl. VAT10,89 EUR

Cooler for Solid State Relay MW-H-150

Cooler for Solid State Relay MW-H-150
In stock
18,50 EUR excl. VAT22,38 EUR

Cooler for Solid State Relay MW-E-105

Cooler for Solid State Relay MW-E-105
On request
14,39 EUR excl. VAT17,41 EUR

SSR holder for DIN rail

SSR holder for DIN rail
In stock
1,19 EUR excl. VAT1,44 EUR
  • Three-phase (3F) solid state relay
  • SSR designed for fast load switching/expansion
  • Load switching at zero
  • Switching indication via LED
  • Control voltage 5...32 Vdc
  • Designed for resistive loads
  • Integrated RC filter
  • Transparent plastic cover included for added safety

Power supplyOther
Control inputDigital signal
Output - relay0x
Output for SSR1x
ProducerMAXWELL electrical limited
TECHNICAL PARAMETERS
Control voltage 5...32 Vdc
Control current 10...68 mA
Switching voltage up to 480 Vac
Maximum switching current 25A
Isolation voltage 2500 Vac
Coverage IP20
Dimensions 105 x 74 x 33 mm
On-Off time max. 10ms
